Designed to provide flush-mount bass augmentation for new and existing background music systems. Features one 5.25-inch (133 mm) woofer that delivers deep bass down to 40 Hz without audible distortion. For indoor applications only.
FEATURES
Low-frequency loudspeaker featuring one 5.25-inch (133 mm) woofer that delivers deep, non-localized bass support down to 40 Hz without audible distortion. For flush, ceiling, pendant and wall-mount applications
Acoustimass speaker technology filters out audible distortion to deliver non-localized bass
Designed to work with the FreeSpace 3 flush and surface satellite speakers, or existing systems where additional bass reinforcement is desired
Module design allows parallel connection of multiple bass modules and can accommodate two or four FreeSpace 3 satellites per bass module
Plenum rated for use in air handling spaces (with optional plenum cover)
Selectable 70/100V or low impedance with transformer tap adjustment under speaker grille
Applications
Designed for a wide range of applications, including:
- Retail stores
- Restaurants and bars
- Lobbies and conference rooms
SPECS
Technical Specification
PHYSICAL
Product Dimensions (H×W×D)
15.4 in × 7.4 in (391 mm ×189 mm), loudspeaker diameter × depth / 14.3 in (362 mm), ceiling hole diameter
Net Weight
14.0 lb (6.4 kg)
Shipping Weight
20.0 lb (9.1 kg)
PERFORMANCE
Frequency Range (-10 dB)
40 Hz – 315 Hz
Calculated Maximum SPL @ 1 m
Per channel: 96 dB continuous, 102 dB peak / Mono: 102 dB continuous, 108 dB peak
Power Handling, long-term continuous
70/100 V: 200 W mono / Low impedance: 50 W per channel stereo or 100 W mono
Transformer Taps, 100V
25 W, 50 W, 100 W, 200 W
Transformer Taps, 70V
25 W, 50 W, 100 W, 200 W
TRANSDUCERS
Mechanical Diagrams
front-view
rear-view
side-view
